• OPTIC.CA - 200GBASE-CWDM4 QSFP-DD - 3HE13853AA-OC - ALCATEL-LUCENT COMPATIBLE
1 1

Technologie Optic.ca Inc.

200GBASE-CWDM4 QSFP-DD, 1270/1290/1310/1330, 2KM, 2xDUPLEX CS, SMF, 100% ALCATEL-LUCENT COMPATIBLE

The Alcatel-Lucent® compatible QSFP-DD 2x 100G CWDM4 (Quad Small Form-Factor Pluggable - Double Density) optical transceiver offers one the highest bandwidth density in the industry. It carries four CWDM optical wavelengths at 25Gb/s each.

Engineered to meet or exceed OEM performance, it supports link lengths of up to 2km on Singlemode fiber and uses a Dual Duplex CS SMF PC/UPC connector. It is fully compliant with the 100G-CWDM4 MSA specifications.

Item Attributes
Compatible Brand Alcatel-Lucent®/Nokia®
Type Transceivers
Cable Type Single-Mode Fiber
Operating Temperature COM (0 °C to 70°C)
Fiber Count 4 Fibers
Wavelength CWDM: 1270 / 1290 / 1310 / 1330nm
Data Rate 200GBASE - 200 Gbps
Form factor QSFP-DD
Max Reach 2km
Connector Type Dual Duplex CS
DDM Yes
Transceiver Type CWDM4
TX Optical Power -6.5dBm to 2.5dBm (Per Lane)
RX Sensitivity -11.5dBm (Per Lane)

CWDM 20nm Spacing Table

View full details

  • Global Compatibility, Canadian Precision

    Every Optic.ca transceiver is coded in-house for flawless compatibility and thoroughly tested to ensure performance across global networking platforms—trusted worldwide, proudly Canadian.

  • Reliability Engineered for Performance

    Our transceivers meet or exceed Tier 1 MTBF standards. Rigorously tested for seamless integration, they deliver OEM-level reliability—while keeping your project on budget.

  • Lifetime Warranty, Total Peace of Mind

    Backed by our lifetime warranty* and unwavering commitment to quality, Optic.ca transceivers deliver the mission-critical reliability your network demands.
