Technologie Optic.ca Inc.

100GBASE-SWDM4 QSFP28, MMF, 850NM, 100M, DUPLEX LC, 100% BROCADE/RUCKUS COMPATIBLE

100% Brocade®/Ruckus® compatible 100GBASE-SWDM4 QSFP28 optical transceiver, designed for high-speed, short distance data transmission. This transceiver utilizes multimode fiber and features a LC UPC connector, ensuring reliable and fast data transmission over a reach of up to 70m with OM3 fiber and 100m with OM4/OM5 fiber.
With years of expertise in custom coding, our transceivers are engineered to meet or exceed OEM technical specifications. Features built-in DDM (Digital Diagnostic Monitoring) and is covered by a lifetime warranty.

Item Attributes
Compatible Brand Brocade®/Ruckus®
Type Transceivers
Cable Type Multimode Fiber
Operating Temperature COM (0 °C to 70°C)
Fiber Count 2 Fibers / Duplex
Wavelength 850nm = 850nm / 880nm / 910nm / 940nm
Data Rate 100GBASE - 100 Gbps
Form factor QSFP28
Max Reach 70m OM3, 100m OM4/OM5
Connector Type LC UPC
DDM Yes
Transceiver Type SWDM4
TX Optical Power -7.5dBm to 3.4dBm (Per Lane)
RX Sensitivity -9.3dBm to 3.4dBm (Per Lane)
