Technologie Optic.ca Inc.
200GBASE-SR4 QSFP-DD, 850NM, 100M OM4, MPO-24, MMF, 100% CISCO COMPATIBLE
The Cisco® compatible QSFP-DD 2x 100G SR4 (Quad Small Form-Factor Pluggable - Double Density) optical transceiver offers one the highest bandwidth density in the industry while maintaining compatibility with two 100GBASE-SR4 transceivers.
Engineered to meet or exceed OEM performance, it supports link lengths of up to 100m on OM4 Multimode fiber and uses a MPO-24 connector. It is fully compliant with the IEEE 802.3 100GBASE-SR4 specifications.
Item Attributes
| Compatible Brand | Cisco® |
| Type | Transceivers |
| Cable Type | Multimode Fiber |
| Operating Temperature | COM (0 °C to 70°C) |
| Fiber Count | 24 Fibers |
| Wavelength | 850nm |
| Data Rate | 200GBASE - 200 Gbps |
| Form factor | QSFP-DD |
| Max Reach | 100m |
| Connector Type | MPO-24 UPC Male |
| DDM | Yes |
| Transceiver Type | SR4 |
| TX Optical Power | -8.4dBm to 2.4dBm (Per Lane) |
| RX Sensitivity | -10.3dBm (Per Lane) |
Share
-
Global Compatibility, Canadian Precision
Every Optic.ca transceiver is coded in-house for flawless compatibility and thoroughly tested to ensure performance across global networking platforms—trusted worldwide, proudly Canadian.
-
Reliability Engineered for Performance
Our transceivers meet or exceed Tier 1 MTBF standards. Rigorously tested for seamless integration, they deliver OEM-level reliability—while keeping your project on budget.
-
Lifetime Warranty, Total Peace of Mind
Backed by our lifetime warranty* and unwavering commitment to quality, Optic.ca transceivers deliver the mission-critical reliability your network demands.
